Compact Disc Player CD-27

Compact Disc Player CD-27; Akai Electric Co., (ID = 1859470) R-Player

Compact Disc Player CD-27; Akai Electric Co., (ID = 1859481) R-Player

Compact Disc Player CD-27; Akai Electric Co., (ID = 1859488) R-Player

Compact Disc Player CD-27; Akai Electric Co., (ID = 1859489) R-Player

Compact Disc Player CD-27; Akai Electric Co., (ID = 1859491) R-Player

Compact Disc Player CD-27; Akai Electric Co., (ID = 1859493) R-Player
Compact Disc Player CD-27; Akai Electric Co., (ID = 1859464) R-Player Compact Disc Player CD-27; Akai Electric Co., (ID = 1859465) R-Player
Use red slider bar for more.
Compact Disc Player CD-27; Akai Electric Co., (ID = 1859464) R-Player
Akai Electric Co.,: Compact Disc Player CD-27 [R-Player] ID = 1859464 1400x1999
Select picture or schematic to display from thumbnails on the right and click for download.
For model Compact Disc Player CD-27, Akai Electric Co., Ltd.; Tokyo:
Akai Service Manual

Country:  Japan
Manufacturer / Brand:  Akai Electric Co., Ltd.; Tokyo
Year: 1991–1993 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details CD-Player, -Writer, MD, MOD (audio); Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220/230/240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Compact Disc Player CD-27 - Akai Electric Co., Ltd.; Tokyo
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 425 x 120 x 351 mm / 16.7 x 4.7 x 13.8 inch
Notes

Akai Single Compact Disc Player Model CD-27.
Digital converter: PCM67P, 18 bit, 8 x oversampling
CD Mechanism: KSS-210A
Frequency response: 2Hz to 20kHz,  Dynamic range: 97dB, Signal to Noise Ratio: 108dB Total harmonic distortion: 0.0035%
Line output: 2V
Digital outputs: coaxial, optical

Accessories:
Akai Remote Control RC-C37

Power Requirements:
Europe except UK - 220-230VAC 50Hz
UK & Australia - 240VAC 50Hz



Net weight (2.2 lb = 1 kg) 4.4 kg / 9 lb 11.1 oz (9.692 lb)
Price in first year of sale 180.00 GBP
Mentioned in - - Manufacturers Literature (Service Manual)

Model page created by Franz Scharner. See "Data change" for further contributors.
