Stereo Tape Deck GX-630 DB

• Country
• Japan

• Manufacturer / Brand
• Akai Electric Co., Ltd.; Tokyo

• Year
• 1975 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 110080

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 64

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 220; Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Various materials

• from Radiomuseum.org
• Model: Stereo Tape Deck GX-630 DB - Akai Electric Co., Ltd.; Tokyo

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 440 x 465 x 240 mm / 17.3 x 18.3 x 9.4 inch

• Notes

• 69 diodes, 2 FETs. 2 speed 4 track 2 channel stereo open reel tape deck with 3-motor direct capstan drive and Dolby.

  Ausführliche Service-Unterlagen bei GX-630D

• Net weight (2.2 lb = 1 kg)
• 19.5 kg / 42 lb 15.2 oz (42.952 lb)

• Source of data
• -- Collector info (Sammler)

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by a member from A. See "Data change" for further contributors.

• Other Models

• Here you find 613 models, 567 with images and 202 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Akai Electric Co., Ltd.; Tokyo
