Three Head/Double Capstan Stereo Cassette Deck GXC325D

Akai Electric Co., Ltd.; Tokyo

Data

Forum

Pictures

Collections

Country
Japan

Manufacturer / Brand
Akai Electric Co., Ltd.; Tokyo

Year
1975

Category
Sound/Video Recorder and/or Player

Radiomuseum.org ID
141733

Schematics

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 780703) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (3)

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 780704) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (3)

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 550240) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (1)

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 1334360) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (1)

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2504671) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (2)
Hersteller-Doku

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2504672) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (2)
Hersteller-Doku

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2504673) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (2)
Hersteller-Doku

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2504674) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (2)
Hersteller-Doku

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2504677) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (2)
Hersteller-Doku

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2504678) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (2)
Hersteller-Doku

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2504679) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (2)
Hersteller-Doku

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2504680) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (2)
Hersteller-Doku

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2504682) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (2)
Hersteller-Doku

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2504683) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (2)
Hersteller-Doku

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2504685) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (2)
Hersteller-Doku

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2504686) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (2)
Hersteller-Doku

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2504688) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (2)
Hersteller-Doku

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2504689) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (2)
Hersteller-Doku

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2729850) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (1)

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2729851) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (1)

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2729852) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (1)

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2729853) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (1)

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2729854) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (1)

Three Head/Double Capstan Stereo Cassette Deck GXC325D; Akai Electric Co., (ID = 2807159) R-Player — Akai Electric Co., Three Head/Double Capstan Stereo Cassette Deck GXC325D (2)
Akai Katalog 1975-76

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Transistors
64

Semiconductors
2SC1312 2SA725 2SC711 2SK34 2SA626 2SC1647 2SC1683 2SC1175 2SD360 WZ085 1N60 1S1588 10D-2 1S2473 1N4001 WZ192

Main principle
Audio-Amplification

Wave bands
- without

Details
Cassette-Recorder or -Player

Power type and voltage
Alternating Current supply (AC) / 110-120 / 220-240 Volt

Loudspeaker
- For headphones or amp.

Material
Various materials

from Radiomuseum.org
Model: Three Head/Double Capstan Stereo Cassette Deck GXC325D - Akai Electric Co., Ltd.; Tokyo

Shape
Tablemodel, with any shape - general.

Dimensions (WHD)
442 x 142 x 301 mm / 17.4 x 5.6 x 11.9 inch

Notes
3-Kopf Cassette Tape Deck mit Monitor-System (Vor/Hinterbandkontrolle umschaltbar), Doppelcapstan-Bandantrieb mit Servo-Regelung des Capstan-Motors.
ADR (Automatic Distortion Reduction System) und Dolby B System.
- Bandgeschwindigkeit 4,76 cm/s (1-⁷/₈ ips)
- Gleichlauf/Wow-flutter < 0,055% (WMRS)
- Frequenzumfang 30-19'000 Hz (±3 dB) mitFeCr-Band
- Nichtlineare Verzerrung (Klirrfaktor) < 1% @ 1 kHz, 0 VU
- Fremdspannungsabstand (S/N ratio) > 51 dB, Verbesserung mit Dolby-System +10 dB oberhalb 5 kHz
Jeder Halbleiter-Typ ist einmal gelistet.

Net weight (2.2 lb = 1 kg)
8.6 kg / 18 lb 15.1 oz (18.943 lb)

Price in first year of sale
1,100.00 DM

Mentioned in
Funk-Technik (FT) (11/76 Seite 355.)

Literature/Schematics (1)
-- Schematic

Author
Model page created by Marc Gianella. See "Data change" for further contributors.
