HiFi-Music-Center AC-3800 L

Akai Electric Co., Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1978
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 218890

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Details
  • Other Combination - see Notes; Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 60 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: HiFi-Music-Center AC-3800 L - Akai Electric Co., Ltd.; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 550 x 220 x 467 mm / 21.7 x 8.7 x 18.4 inch
  • Notes
  • Akai HiFi Music Center AC-3800 L, Kombi-Gerät aus Plattenspieler, Kassettenrekorder, Radio und Verstärker.
    2 x 30 Watt Sinusleistung,
    2 x 40 Watt Musikleistung,
    Plattenspieler: Riemenantrieb, 33 1/3 und 45 U/min.
  • Net weight (2.2 lb = 1 kg)
  • 17.5 kg / 38 lb 8.7 oz (38.546 lb)
  • Source of data
  • -- Original prospect or advert
