Solid State Stereo Pre-Main Amplifier AA-5500

• Country
• Japan

• Manufacturer / Brand
• Akai Electric Co., Ltd.; Tokyo

• Year
• 1973–1975 ??

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 251056

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 17

• Semiconductors
• LD3120 LD3120 LD3120 LD3120 LD3120 2SA606 2SA606 2SC900 2SC900 2SC900 2SC900 2SC900 2SC900 2SC959 2SC959 2SC959 2SC959 2SC968 2SD188 2SD188 2SD188 2SD188

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 100 - 240 (50-60 Hz) / 117 (60Hz) Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 90 W (120 W max.)

• Material
• Metal case

• from Radiomuseum.org
• Model: Solid State Stereo Pre-Main Amplifier AA-5500 - Akai Electric Co., Ltd.; Tokyo

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 432 x 143 x 330 mm / 17 x 5.6 x 13 inch

• Notes

• Akai Solid State Stereo Pre-Main Amplifier Model AA-5500.
  Inputs: AUX, Tuner, Phono1, Phono2, Tape1, Tape2, Mic
  Bass- & Treble-Control, Loudness, Low Cut & High Cut Filter
  Power Consumption 300 Watts



• Net weight (2.2 lb = 1 kg)
• 9.9 kg / 21 lb 12.9 oz (21.806 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
