Stereo Tape Deck GX-370D
Akai Electric Co.,: Stereo Tape Deck GX-370D [R-Player] ID = 1631725 885x1063
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1975 ?? | Category: Sound/Video Recorder and/or Player | ||||
| Semiconductors (the count is only for transistors) | Semiconductors present. | ||||
|---|---|---|---|---|---|
| schematic requested | |||||
| Main principle | Audio-Amplification |
|---|---|
| Wave bands | - without |
| Details | Tape Recorder; Hi-Fi equipment |
| Power type and voltage | Alternating Current supply (AC) / 100-240 Volt |
| Loudspeaker | - For headphones or amp. |
| Power out | |
| from Radiomuseum.org | Model: Stereo Tape Deck GX-370D - Akai Electric Co., Ltd.; Tokyo |
| Material | Various materials |
| Shape | Tablemodel, with any shape - general. |
| Dimensions (WHD) | 445 x 503 x 252 mm / 17.5 x 19.8 x 9.9 inch |
| Net weight (2.2 lb = 1 kg) | 25.5 kg / 56 lb 2.7 oz (56.167 lb) |
| Mentioned in | -- Original-techn. papers. |
Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
