Stereo Tape Recorder 4400

Akai Electric Co., Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1970 ??
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 276569

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC)
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 16 W (max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Stereo Tape Recorder 4400 - Akai Electric Co., Ltd.; Tokyo
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 406 x 314 x 194 mm / 16 x 12.4 x 7.6 inch
  • Notes

  • Akai Stereo Tape Recorder Model 4400.
    4-track, 2-channel stereo
    Reel Capacity up to 7" reel
    Tape Speed 7,5 and 3,75 ips +/-2%
    Wow and Flutter less than 0,15% RMS at 7,5 ips
    Frequency Response:
    +/-3dB 7,5ips 30 - 23000Hz
    +/.3dB 3,75ips 30-15000Hz
    Inputs: Mic 0,8mV, 5kOhms, Line Input 70mV, 150kOhms, DIN Input 7mV
    SpeakerOutput:
    16 Watts total Music Power at 8 Ohms
    12 Watts continous Power at 8 Ohms
    Bias Frequency 105kHz +/-5%
    Power Requirements:
    100 to 240VAC, 50/60Hz
    120VAC 60Hz - CSA/UL Models
    220VAC, 50Hz - CEE Models



  • Net weight (2.2 lb = 1 kg)
  • 13.7 kg / 30 lb 2.8 oz (30.176 lb)
  • Mentioned in
  • - - Manufacturers Literature (Service Manual)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
