TV-Tuner VTU-E

TV-Tuner VTU-E; Akai Electric Co., (ID = 263682) Television TV-Tuner VTU-E; Akai Electric Co., (ID = 668764) Television
Use red slider bar for more.
TV-Tuner VTU-E; Akai Electric Co., (ID = 263682) Television
Akai Electric Co.,: TV-Tuner VTU-E [Television] ID = 263682 776x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model TV-Tuner VTU-E, Akai Electric Co., Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  Akai Electric Co., Ltd.; Tokyo
Year: 1972/1973 ? Category: Television Receiver (TV) or Monitor
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Powered by external power supply or a main unit. / 12 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: TV-Tuner VTU-E - Akai Electric Co., Ltd.; Tokyo
Material Plastics (no bakelite or catalin)
Dimensions (WHD) 4.4 x 3.8 x 10.3 inch / 112 x 97 x 262 mm
Notes Zusatzgerät zu den Videorecordern VT100 & VT110. VHF/UHF.
Net weight (2.2 lb = 1 kg) 1.7 kg / 3 lb 11.9 oz (3.744 lb)
Source of data - - Data from my own collection
Mentioned in -- Original prospect or advert

Model page created by Heinz Westerweller. See "Data change" for further contributors.
