Bleistiftmikrofon C 747

AKG Acoustics GmbH; Wien

  • Year
  • 2002 ?
  • Category
  • Microphone or Pick-up element
  • Radiomuseum.org ID
  • 245705
    • alternative name: AKG Akustische- ...München - siehe Austria
    • Brand: Akustische- und Kino-Geräte GmbH

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • Powered by external power supply or a main unit. / 9-52 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Bleistiftmikrofon C 747 - AKG Acoustics GmbH; Wien
  • Dimensions (WHD)
  • 9 x 135 x 9 mm / 0.4 x 5.3 x 0.4 inch
  • Notes
  • Das Bleistiftmikrofon "C 747" von AKG ist ein kleines Richtmikrofon, das zur Lösung
    schwieriger Aufstellungsprobleme bei Chor und Orchester, Bühnen oder Konferenz-
    Räumen entwickelt wurde.

    Einige technische Daten:
    Richtcharakteristik: Hyperniere
    Übertragungsbereich: 30-18.000 Hz
    Elektrische Impedanz: 400 Ohm
    Speisespannung: 9-52 V (Phantomspeisung)
    Anschluss: 3-pol. XLR-Stecker
    Kabellänge: 3 m
    Gewicht mit Stativ-Halter: 750 g.

  • Author
  • Model page created by Jürgen Küting. See "Data change" for further contributors.
