- Country
- Austria
- Manufacturer / Brand
- AKG Acoustics GmbH; Wien
- Year
- 1962–1965
- Category
- Microphone or Pick-up element
- Radiomuseum.org ID
- 74829
-
- alternative name: AKG Akustische- ...München - siehe Austria
- Brand: Akustische- und Kino-Geräte GmbH
Q: AKG, Katalog Kurzprogramm '67
Q: AKG, Katalog Kurzprogramm '67
Click on the schematic thumbnail to request the schematic as a free document.
- Power type and voltage
- No Power needed
- Material
- Metal case
- from Radiomuseum.org
- Model: D19C - AKG Acoustics GmbH; Wien
- Shape
- Miscellaneous shapes - described under notes.
- Dimensions (WHD)
- 38 x 152 x 21 mm / 1.5 x 6 x 0.8 inch
- Notes
- Dynamisches Mikrofon mit Cardioid-Charakteristik. Frequenzgang 30 bis 16000 Hz. Impedanz 60 Ohm als D19C/60 oder 200 Ohm als D19C/200. Empfindlichkeit bei 60 Ohm 0,1mV/µbar, bei 200 Ohm 0,18mV/µbar. Anschluß: eingebauter 3 pol. DIN-Stecker.
- Net weight (2.2 lb = 1 kg)
- 0.2 kg / 0 lb 7 oz (0.441 lb)
- Source of data
- -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb
- Mentioned in
- Funk-Technik (FT) (18/1962, S. 616 / Beschreibung, Neuvorstellung)
- Author
- Model page created by Werner Raacke. See "Data change" for further contributors.
- Other Models
-
Here you find 180 models, 170 with images and 58 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from AKG Acoustics GmbH; Wien
Collections
The model is part of the collections of the following members.
Forum contributions about this model: AKG Acoustics GmbH;: D19C
Threads: 1 | Posts: 1
From the AKG brochure:
For news reports, conferences, lectures, for the many uses of the sound hobbyist, and as a microphone for musicians, the D 19 has virtually evolved into the symbol of the modern directional microphone. A slender, convenient shape and high-quality workmanship are the external characteristics of the D 19C. Its extraordinary reputation as a resonably priced universal microphone is based on its excellent directional characteristic, combined with its wide frequency response and a continous bass attenuator. A complete, ready-to-use microphone system for the demanding hobbyist was created in the form of the D 19C comb. (table stand, connecting cable, stand adapter).
Bo Samuelsson, 27.Jan.07
