Combiphon 844 / 7600

Combiphon 844 / 7600; Akkord-Radio + (ID = 1012371) Radio

Combiphon 844 / 7600; Akkord-Radio + (ID = 1012372) Radio

Combiphon 844 / 7600; Akkord-Radio + (ID = 1012375) Radio

Combiphon 844 / 7600; Akkord-Radio + (ID = 1012376) Radio

Combiphon 844 / 7600; Akkord-Radio + (ID = 1012373) Radio

Combiphon 844 / 7600; Akkord-Radio + (ID = 1012374) Radio
Combiphon 844 / 7600; Akkord-Radio + (ID = 2569457) Radio
Use red slider bar for more.
Combiphon 844 / 7600; Akkord-Radio + (ID = 2569457) Radio
Akkord-Radio +: Combiphon 844 / 7600 [Radio] ID = 2569457 900x833
Select picture or schematic to display from thumbnails on the right and click for download.
For model Combiphon 844 / 7600, Akkord-Radio + Akkord Elektronik (Radios):
Legende in Schaltplansammlung des Herstellers

Country:  Germany
Manufacturer / Brand:  Akkord-Radio + Akkord Elektronik (Radios)
Year: 1968 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 20:
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Batteries / addl. power jack
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Combiphon 844 / 7600 - Akkord-Radio + Akkord
Material Various materials
Shape Portable set > 8 inch (also usable without mains)
Notes

Radiorecorder, mit Autohalterung auch als Autoradio-Cassette verwendbar.

Exportversion des Combiphon  840 mit:

  • Beschriftung in englischer Sprache
  • Änderung der 4 Wellenbereiche, z.B. UKW/FM bis 108 MHz
Source of data -- Original-techn. papers.

Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
