Offenbach 52NB6

Offenbach 52NB6; Akkord-Radio + (ID = 364653) Radio

Offenbach 52NB6; Akkord-Radio + (ID = 1019749) Radio
Offenbach 52NB6; Akkord-Radio + (ID = 306959) Radio Offenbach 52NB6; Akkord-Radio + (ID = 2385244) Radio
Offenbach 52NB6; Akkord-Radio + (ID = 2385245) Radio
Use red slider bar for more.
Offenbach 52NB6; Akkord-Radio + (ID = 306959) Radio
Akkord-Radio +: Offenbach 52NB6 [Radio] ID = 306959 477x407
Select picture or schematic to display from thumbnails on the right and click for download.
For model Offenbach 52NB6, Akkord-Radio + Akkord Elektronik (Radios)

Country:  Germany
Manufacturer / Brand:  Akkord-Radio + Akkord Elektronik (Radios)
Year: 1952/1953 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: DF91 DK91 DF91 DAF91 DL92
Main principle Superheterodyne (common); ZF/IF 473 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Line / Batteries (any type) / AC/DC 117-220 / 9 & 80 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
Power out
from Radiomuseum.org Model: Offenbach 52NB6 - Akkord-Radio + Akkord
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 380 x 270 x 120 mm / 15 x 10.6 x 4.7 inch
Notes Eingebaute Rahmenantenne. Kunstlederbezug; Lederbezug gegen Mehrpreis (60,- DM).
Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)
Price in first year of sale 288.00 DM
Source of data Kat.d.Rundf.GrossH.1952/53

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
