Alan 456R PMR 446

Alan 456R PMR 446; CTE international S. (ID = 2314710) Commercial TRX Alan 456R PMR 446; CTE international S. (ID = 2314711) Commercial TRX
Alan 456R PMR 446; CTE international S. (ID = 2317487) Commercial TRX
Use red slider bar for more.
Alan 456R PMR 446; CTE international S. (ID = 2314710) Commercial TRX
CTE international S.: Alan 456R PMR 446 [Commercial TRX] ID = 2314710 565x1148
Select picture or schematic to display from thumbnails on the right and click for download.
For model Alan 456R PMR 446, CTE international S.r.l. ; Mancasale

Country:  Italy
Manufacturer / Brand:  CTE international S.r.l. ; Mancasale
Year: 2005 ? Category: Commercial Transmitter & Receiver (TRX not Amateur)
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superhet, double/triple conversion; ZF/IF 21400/455 kHz
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Storage and/or dry batteries / 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 cm = 1.6 inch
Power out 0.3 W (0.3 W max.)
from Radiomuseum.org Model: Alan 456R PMR 446 - CTE international S.r.l. ;
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 53 x 95 x 30 mm / 2.1 x 3.7 x 1.2 inch
Notes

PMR-Handfunkgerät mit 0,5 Watt Sendeleistung

Anmelde- und gebührenfrei
446,00625 - 446,09375 MHZ, 12,5 kHz-Raster
mit fest angebauter Antenne.
Frequenzmodulation

Vertrieb für Deutschland:

Alan Electronics GmbH
Daimlerstraße 1K
63303 Dreieich

Net weight (2.2 lb = 1 kg) 0.110 kg / 0 lb 3.9 oz (0.242 lb)

Model page created by Alois Wolf. See "Data change" for further contributors.
