Lyric 606 Batt.

Lyric 606 Batt. ; All American Mohawk, (ID = 1036115) Radio Lyric 606 Batt. ; All American Mohawk, (ID = 1036113) Radio
Lyric 606 Batt. ; All American Mohawk, (ID = 1036114) Radio Lyric 606 Batt. ; All American Mohawk, (ID = 1036116) Radio
Lyric 606 Batt. ; All American Mohawk, (ID = 1036117) Radio Lyric 606 Batt. ; All American Mohawk, (ID = 1036118) Radio
Lyric 606 Batt. ; All American Mohawk, (ID = 1036119) Radio Lyric 606 Batt. ; All American Mohawk, (ID = 1036120) Radio
Lyric 606 Batt. ; All American Mohawk, (ID = 1036121) Radio Lyric 606 Batt. ; All American Mohawk, (ID = 1036122) Radio
Use red slider bar for more.
Lyric 606 Batt. ; All American Mohawk, (ID = 1036115) Radio
All American Mohawk,: Lyric 606 Batt. [Radio] ID = 1036115 646x800
Select picture or schematic to display from thumbnails on the right and click for download.
For model Lyric 606 Batt., All American Mohawk, Rauland Lyric; Chicago:
Ebay user letemglow 300582621456

Country:  United States of America (USA)
Manufacturer / Brand:  All American Mohawk, Rauland Lyric; Chicago
alternative name

All American Electrical Manufacturers || All-American Radio || American Mohawk || Mohawk Corporation of Illinois || Mohawk Electric Corporation || Rauland Mfg.Co.
Year: 1932 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UX171A UX201A UX201A UX201A UX201A UX201A
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage and/or dry batteries / ? & 45 & 90 & 160 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Lyric 606 Batt. - All American Mohawk, Rauland
Material Wooden case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Dimensions (WHD) 440 x 340 x 220 mm / 17.3 x 13.4 x 8.7 inch
Net weight (2.2 lb = 1 kg) 13 kg / 28 lb 10.1 oz (28.634 lb)
Collectors' prices
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 3 = 1933 and before


All listed radios etc. from All American Mohawk, Rauland Lyric; Chicago
Here you find 204 models, 76 with images and 90 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
