Model R Compartment Cabinet

Model R; All American Mohawk, (ID = 689896) Radio
Model R; All American Mohawk, (ID = 1858385) Radio Model R; All American Mohawk, (ID = 757724) Radio
Model R; All American Mohawk, (ID = 1304511) Radio Model R; All American Mohawk, (ID = 1381971) Radio
Model R; All American Mohawk, (ID = 1744169) Radio Model R; All American Mohawk, (ID = 1744170) Radio
Model R; All American Mohawk, (ID = 1858386) Radio Model R; All American Mohawk, (ID = 1858387) Radio
Model R; All American Mohawk, (ID = 1858388) Radio Model R; All American Mohawk, (ID = 1858389) Radio
Use red slider bar for more.
Model R; All American Mohawk, (ID = 1858385) Radio
All American Mohawk,: Model R [Radio] ID = 1858385 1400x811
Select picture or schematic to display from thumbnails on the right and click for download.
For model Model R Compartment Cabinet, All American Mohawk, Rauland Lyric; Chicago:
eBay item number:141700123863

Country:  United States of America (USA)
Manufacturer / Brand:  All American Mohawk, Rauland Lyric; Chicago
alternative name

All American Electrical Manufacturers || All-American Radio || American Mohawk || Mohawk Corporation of Illinois || Mohawk Electric Corporation || Rauland Mfg.Co.
Year: 1925 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UX201A UX201A UX201A UX201A UX201A
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage and/or dry batteries
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Model R [Compartment Cabinet] - All American Mohawk, Rauland
Material Wooden case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Notes

Two dials (primary tuning control knobs)

All-American Model R with compartment cabinet large enough to hold needed batteries.

Price in first year of sale 90.00 $
Collectors' prices
External source of data Ernst Erb
Source of data Radio Collector`s Guide 1921-1932
Circuit diagram reference Rider's Perpetual, Volume 3 = 1933 and before
Mentioned in The Radio Collector's Directory and Price Guide 1921 - 1965
Literature/Schematics (2) Radio Broadcast, Mar. 1926, p. 599
Literature/Schematics (4) Radio Broadcast Magazine (October 1926, Radio Broadcast magazine advertisement on page 449)


All listed radios etc. from All American Mohawk, Rauland Lyric; Chicago
Here you find 204 models, 76 with images and 90 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
