Knight 14F495

Knight 14F495 ; Allied Radio Corp. (ID = 265803) Radio

Knight 14F495 ; Allied Radio Corp. (ID = 265804) Radio

Knight 14F495 ; Allied Radio Corp. (ID = 265805) Radio

Knight 14F495 ; Allied Radio Corp. (ID = 265806) Radio

Knight 14F495 ; Allied Radio Corp. (ID = 265807) Radio

Knight 14F495 ; Allied Radio Corp. (ID = 1282750) Radio

Knight 14F495 ; Allied Radio Corp. (ID = 1282752) Radio

Knight 14F495 ; Allied Radio Corp. (ID = 1282753) Radio

Knight 14F495 ; Allied Radio Corp. (ID = 1282754) Radio

Knight 14F495 ; Allied Radio Corp. (ID = 1282755) Radio
Use red slider bar for more.
Knight 14F495 ; Allied Radio Corp. (ID = 265803) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)
Year: 1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 14: 6BA6 6BA6 6BE6 6BE6 6U5 6C4 6SG7 6SH7 6AL5 6SQ7 7F7 6V6GT 6V6GT 5Y3GT
Main principle Superheterodyne (common); ZF/IF 455-10.7MH kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker - This model requires external speaker(s). / Ø 11.5 inch = 29.2 cm
Power out
from Radiomuseum.org Model: Knight 14F495 - Allied Radio Corp. Knight,
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 19 = 1949 and before
Mentioned in Photofact Folder, Howard W. SAMS (Volume 7 Folder 4911-12 05/1949)


All listed radios etc. from Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)
Here you find 972 models, 570 with images and 641 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
