Marconi P2 Ch= 48-00 series

Marconi P2 Ch= 48-00 series; Amalgamated Wireless (ID = 2180608) Television

Marconi P2 Ch= 48-00 series; Amalgamated Wireless (ID = 2180609) Television

Marconi P2 Ch= 48-00 series; Amalgamated Wireless (ID = 2180610) Television

Marconi P2 Ch= 48-00 series; Amalgamated Wireless (ID = 2180611) Television

Marconi P2 Ch= 48-00 series; Amalgamated Wireless (ID = 2180612) Television

Marconi P2 Ch= 48-00 series; Amalgamated Wireless (ID = 2180613) Television

Marconi P2 Ch= 48-00 series; Amalgamated Wireless (ID = 2180614) Television

Marconi P2 Ch= 48-00 series; Amalgamated Wireless (ID = 2180615) Television

Marconi P2 Ch= 48-00 series; Amalgamated Wireless (ID = 2180616) Television

Marconi P2 Ch= 48-00 series; Amalgamated Wireless (ID = 2180617) Television
Marconi P2 Ch= 48-00 series; Amalgamated Wireless (ID = 1600888) Television Marconi P2 Ch= 48-00 series; Amalgamated Wireless (ID = 1600889) Television
Marconi P2 Ch= 48-00 series; Amalgamated Wireless (ID = 1190641) Television
Use red slider bar for more.
Marconi P2 Ch= 48-00 series; Amalgamated Wireless (ID = 1600888) Television
Amalgamated Wireless: Marconi P2 Ch= 48-00 series [Television] ID = 1600888 870x657
Select picture or schematic to display from thumbnails on the right and click for download.
For model Marconi P2 Ch= 48-00 series, Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney:
The front of my 1966 AWA P2 portable-tabletop television receiver.

Country:  Australia
Manufacturer / Brand:  Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
Year: 1965–1967 Category: Television Receiver (TV) or Monitor
Valves / Tubes 14: 6GK5 6HG8 6EH7 6EJ7 6KV8 6CS6 6HG5 6CB6 6GV8 12AU7A 6CM5 6AU4GTA 1B3GT 19FNP4
Semiconductors (the count is only for transistors) 1N87A 1N3194 1N3194
Main principle Superhet with RF-stage; ZF/IF 36875/31375 kHz; 1 AF stage(s)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220-240; 250-260 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Marconi P2 Ch= 48-00 series - Amalgamated Wireless
Material Leather / canvas / plastic - over other material
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 23 x 16 x 12 inch / 584 x 406 x 305 mm
Notes

19" television set tuning the 13 Australian standard VHF channels.

Vinyl covered timber cabinet. Colours available in Dusty Rose Pink, Royal Oak Brown, Desert Blue & Maple Woodgrain.

Price in first year of sale 270.90 AUS $
Literature/Schematics (1) - - Manufacturers Literature (AWA Manufacturers Supervised Service, May 1966.)
Literature/Schematics (2) J.R. Publications Television Service Handbook (Group 8-18, August 1966, Page A102.)

Model page created by Stuart Irwin. See "Data change" for further contributors.
