C52820

Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney

Data
Forum
Pictures
Collections

  • Year
  • 1955
  • Category
  • Amateur-Receiver (amateur bands, may include broadcast bands)
  • Radiomuseum.org ID
  • 310093

 Technical Specifications

  • Number of Tubes
  • 11
  • Main principle
  • Superhet with RF-stage; ZF/IF 565 kHz; 2 AF stage(s); none
  • Tuned circuits
  • 1 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and more than two Short Wave bands.
  • Power type and voltage
  • Alternating Current supply (AC) / 200-260V Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm
  • Power out
  • 0.2 W (undistorted)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: C52820 - Amalgamated Wireless
  • Shape
  • Tablemodel, Box - most often with Lid (NOT slant panel).
  • Dimensions (WHD)
  • 20 x 13 x 14 inch / 508 x 330 x 356 mm
  • Notes

  • 5 Bands covering 100kHz to 32MHz. IF for the broadcast band is 515kHz. Power output to an external speaker is 2W. The radio can be mounted in a 19 inch rack. Provides reception for R.T., M.C.W. and C.W.

  • Net weight (2.2 lb = 1 kg)
  • 67 lb (67 lb 0 oz) / 30.418 kg
  • Author
  • Model page created by Mark Hellewell. See "Data change" for further contributors.
