Orthofidelity AM3

Amalgamated Wireless Australasia (NZ) Ltd. (AWA); Wellington

Data
Forum
Pictures
Collections

  • Year
  • 1973 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 304778

 Technical Specifications

  • Number of Transistors
  • 7
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Alternating Current supply (AC) / 50Hz, 230-250 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Orthofidelity AM3 - Amalgamated Wireless
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 16 x 4.5 x 8 inch / 406 x 114 x 203 mm
  • Notes

  • AWA AM3 Orthiofidelity Tuner

    Broadcast (MW) tuner with silicone planar transistors, tuned RF stage, and 2 audio outputs. Control knobs set in silver and black satin fascia in matching mahogany veneer.

  • Net weight (2.2 lb = 1 kg)
  • 7 lb 0 oz (7 lb) / 3.178 kg
  • Price in first year of sale
  • 115.00 NZ $
  • Mentioned in
  • -- Original prospect or advert (Press 11 August 1973 Page 9)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (AWA Orthofidelity Handbook.)
  • Author
  • Model page created by Martin Kent. See "Data change" for further contributors.
