- Country
- Australia
- Manufacturer / Brand
- Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
- Year
- 1937/1938
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 167942
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz; 2 AF stage(s)
- Tuned circuits
- 8 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Storage and/or dry batteries / 135 & 2 & -1.5 & -3 & -4.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: Radiola 50 - Amalgamated Wireless
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Price in first year of sale
- 26.00 Aus£
- Circuit diagram reference
- Australian Official Radio Service Manual Vol. I I
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
