Radiola 52GW

Radiola 52GW; Amalgamated Wireless (ID = 718831) Radio
Use red slider bar for more.
Radiola 52GW; Amalgamated Wireless (ID = 718831) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Australia
Manufacturer / Brand:  Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6A8G 6U7G 6G8G 6F6G 5Y3G
Main principle Super-Heterodyne (Super in general); ZF/IF 460 kHz; 2 AF stage(s); Reflex
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 200-260 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Radiola 52GW - Amalgamated Wireless
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Notes

This radio is identical to the model 52G except for the use of a wooden case.

Price in first year of sale 21.00 Aus£
Circuit diagram reference Australian Official Radio Service Manual Vol. III
Mentioned in HRSA Radio Waves, # 139, January 2017, Page 8.
Literature/Schematics (1) Mingay's Radio Diagram & I.F. Index

Model page created by Stuart Irwin. See "Data change" for further contributors.
