Radiola 581PY

Radiola 581PY; Amalgamated Wireless (ID = 2410035) Radio
Use red slider bar for more.
Radiola 581PY; Amalgamated Wireless (ID = 2410035) Radio
Amalgamated Wireless: Radiola 581PY [Radio] ID = 2410035 1400x914
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radiola 581PY, Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney

Country:  Australia
Manufacturer / Brand:  Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney
Year: 1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 1R5 1T4 1U5 3V4 6X4
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Line / Batteries (any type) / 195-215; 216-235; 236-255 / 7.5 & 90 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out 0.2 W (undistorted)
from Radiomuseum.org Model: Radiola 581PY - Amalgamated Wireless
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Notes

Portable Battery/AC radio with battery reactivation.

Battery types used: (A) 7½V Eveready 719 or Diamond 3719 & (B) Eveready Mini-Max 490P or Diamond 3490.

Case available in Natural Leather or Black, Red, Grey & Fawn plastic covered.

Price in first year of sale 32.55 AUS £
Literature/Schematics (1) - - Manufacturers Literature (AWA Radiola Technical Information & Service Data.)
Literature/Schematics (2) J.R. Publications Radio Service Handbook (R.V. Series Vol. 1, 1963, Page A118.)

Model page created by Stuart Irwin. See "Data change" for further contributors.
