U.S.A.A.F. Amenities Receiver IC-17020

Amalgamated Wireless (Australasia) Ltd. (AWA); Sydney

Data
Forum
Pictures
Collections

  • Year
  • 1945
  • Category
  • Military Receiver
  • Radiomuseum.org ID
  • 265027

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superhet with RF-stage; ZF/IF 465 kHz; 2 AF stage(s)
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Alternating Current supply (AC) / 110 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6 inch = 15.2 cm
  • Power out
  • 5 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: U.S.A.A.F. Amenities Receiver IC-17020 - Amalgamated Wireless
  • Shape
  • Boatanchor (heavy military or commercial set >20 kg).
  • Dimensions (WHD)
  • 16 x 11 x 14 inch / 406 x 279 x 356 mm
  • Notes

  • This radio was made for the United States Army Air Force in 1945. It is a variant of the C-17020 that was used by the Australian army as a morale (amenities) receiver. Primarily used for entertainment, this radio boasts a shortwave band as well as the standard broadcast band. The 6 inch electrodynamic speaker provides substantial audio with very pleasing fidelity. The main difference between the U.S.A.A.F. version and the Australian version is the power supply. The Australian version had a 6 volt DC vibrator supply and the U.S.A.A.F. version operated on 110 Volts AC.

  • Net weight (2.2 lb = 1 kg)
  • 35 lb 0 oz (35 lb) / 15.890 kg
  • Author
  • Model page created by Ross Hochstrasser. See "Data change" for further contributors.
