Junior AR39

Junior AR39; Amplion, Alfred (ID = 388377) Speaker-P Junior AR39; Amplion, Alfred (ID = 136015) Speaker-P
Junior AR39; Amplion, Alfred (ID = 136016) Speaker-P Junior AR39; Amplion, Alfred (ID = 136017) Speaker-P
Junior AR39; Amplion, Alfred (ID = 136018) Speaker-P Junior AR39; Amplion, Alfred (ID = 226558) Speaker-P
Junior AR39; Amplion, Alfred (ID = 388570) Speaker-P Junior AR39; Amplion, Alfred (ID = 1001400) Speaker-P
Junior AR39; Amplion, Alfred (ID = 1001401) Speaker-P
Use red slider bar for more.
Junior AR39; Amplion, Alfred (ID = 388377) Speaker-P
Amplion, Alfred: Junior AR39 [Speaker-P] ID = 388377 845x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Junior AR39, Amplion, Alfred Graham; GB (see also USA):
Amplion AR39 - coil resistance 2000 Ohm - serial number D7536

Country:  Great Britain (UK)
Manufacturer / Brand:  Amplion, Alfred Graham; GB (see also USA)
Year: 1924 Category: Loudspeaker, headphone or earphone
Details
Power type and voltage No Power needed
Loudspeaker Horn
Power out
from Radiomuseum.org Model: Junior AR39 - Amplion, Alfred Graham; GB see
Material Metal case
Dimensions (WHD) 180 x 120 x 180 mm / 7.1 x 4.7 x 7.1 inch
Notes Amplion Junior AR-39
Net weight (2.2 lb = 1 kg) 1.7 kg / 3 lb 11.9 oz (3.744 lb)
Price in first year of sale 18.00 $
Collectors' prices
Source of data -- Collector info (Sammler)
Literature/Schematics (4) Radio for March 1924 advertisement page 49

Model page created by Heinz Schmidt. See "Data change" for further contributors.



All listed radios etc. from Amplion, Alfred Graham; GB (see also USA)
Here you find 85 models, 62 with images and 8 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
