CL769 avec ECH42, EAF42

CL769; Amplix CGTVE; Paris (ID = 1675153) Radio CL769; Amplix CGTVE; Paris (ID = 1675154) Radio
CL769; Amplix CGTVE; Paris (ID = 539453) Radio CL769; Amplix CGTVE; Paris (ID = 1724025) Radio
Use red slider bar for more.
CL769; Amplix CGTVE; Paris (ID = 1675153) Radio
Amplix CGTVE; Paris: CL769 [Radio] ID = 1675153 800x571
Select picture or schematic to display from thumbnails on the right and click for download.
For model CL769 avec ECH42, EAF42, Amplix (CGTVE); Paris:
Toute la radio 1950

Country:  France
Manufacturer / Brand:  Amplix (CGTVE); Paris
Year: 1950 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: EF41 ECH42 EF41 EAF42 EM4 EL41 GZ40
Main principle Superhet with RF-stage; 2 AF stage(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 130; 145; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 24 cm = 9.4 inch
Power out
from Radiomuseum.org Model: CL769 [avec ECH42, EAF42] - Amplix CGTVE; Paris
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 660 x 400 x 285 mm / 26 x 15.7 x 11.2 inch
Notes

2 OC dont une bande étalée (BE). Clavier à 11 touches (Visomatic). Antenne cadre blindé cylindrique incorporé.

Literature/Schematics (1) Toute la radio (1950)
Literature/Schematics (2) Le grand livre de la TSF (fiche N° 22170)
