Gevoelige MG afstemmer UN-53
Amroh NV (Radio Bulletin monthly), Muiden
- Country
- Netherlands
- Manufacturer / Brand
- Amroh NV (Radio Bulletin monthly), Muiden
- Year
- 1958
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 256485
picture shows the back side of the UN-53
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Main principle
- Superheterodyne (common); ZF/IF 467.5 kHz
- Tuned circuits
- 8 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Powered by external power supply or a main unit. / DC 250 & AC 6.3 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Various materials
- from Radiomuseum.org
- Model: Gevoelige MG afstemmer UN-53 - Amroh NV Radio Bulletin
- Shape
- Chassis only or for «building in»
- Notes
-
Power supply is to be taken from an amplifier delivering 7 mA at 250 V DC and 6.3 V AC for the two tubes.
- Price in first year of sale
- 54.60 NLG
- Literature/Schematics (1)
- Radio Bulletin (May 1958)
- Author
- Model page created by Rob Majoor. See "Data change" for further contributors.
