Wiramphone 72001
Amroh NV Radio: Wiramphone 72001 [R-Player] ID = 184275 640x468
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1948–1950 | Category: Sound/Video Recorder and/or Player | ||||
| Valves / Tubes | 4: EF22 EF50 EL3N AZ1 |
|---|
| Main principle | Audio-Amplification; 3 AF stage(s) |
|---|---|
| Wave bands | - without |
| Details | Other Combination - see Notes |
| Power type and voltage | Alternating Current supply (AC) / 110; 125; 150; 220 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch |
| Power out | 4 W (unknown quality) |
| from Radiomuseum.org | Model: Wiramphone 72001 - Amroh NV Radio Bulletin |
| Material | Leather / canvas / plastic - over other material |
| Shape | Tablemodel, low profile (big size). |
| Dimensions (WHD) | 380 x 240 x 420 mm / 15 x 9.4 x 16.5 inch |
| Notes | Wire recorder-gramophone player. USA made recorder-phono deck, Armour Research Foundation licence. Wire speed 24 inch/sec, phono speed 78 rpm. Max. recording time 60 min. Amplifier made by Amroh, case made by Terwijn & Zn, Koffer & Lederwarenfabriek Rotterdam. Phono cartridge Astatic L71A. Later variant 72002 has EF40 microphone amplifier instead of EF22 |
| Net weight (2.2 lb = 1 kg) | 19 kg / 41 lb 13.6 oz (41.85 lb) |
| Price in first year of sale | 800.00 Dfl |
| Literature/Schematics (1) | -- Original-techn. papers. |
Model page created by John Hupse † 28.9.20. See "Data change" for further contributors.
