• Country
• Italy

• Manufacturer / Brand
• Amtron, (High-Kit, Amtroncraft); Milano

• Year
• 1974 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 197172

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 2

• Semiconductors
• 2N3819 BC209 AA119 AA119

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Dry Batteries / 6 x 1,5 or 1 x 9 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Grid-dip meter UK402 - Amtron, High-Kit, Amtroncraft;

• Dimensions (WHD)
• 156 x 77 x 57 mm / 6.1 x 3 x 2.2 inch

• Notes

• Gamme de fréquences: de 2.8 à 155 MHz, en 5 gammes.

  Frequenza di lavoro da 2,8 a 155 MHz suddivisa in 5 gamme:
  2,8÷7, 6÷13, 11,5÷27, 26÷64, 60÷155 MHz.
  I primi apparecchi utilizzavano 6 batterie da 1,5 V. Gli ultimi usano (o usavano) una sola batteria da 9 V.

• Net weight (2.2 lb = 1 kg)
• 0.4 kg / 0 lb 14.1 oz (0.881 lb)

• Price in first year of sale
• 508.00 FF

• Mentioned in
• - - Manufacturers Literature

• Literature/Schematics (2)
• -- Original-techn. papers. (Da: “CQ Elettronica”, CD edizioni numero 3, marzo 1974.)

• Author
• Model page created by Jean Marchal. See "Data change" for further contributors.
