Anglo-Nordic 290-FM bafle rejilla madera

Anglo-Nordic 290-FM; Anglo Española de (ID = 359492) Radio Anglo-Nordic 290-FM; Anglo Española de (ID = 359493) Radio
Anglo-Nordic 290-FM; Anglo Española de (ID = 359494) Radio Anglo-Nordic 290-FM; Anglo Española de (ID = 359495) Radio
Use red slider bar for more.
Anglo-Nordic 290-FM; Anglo Española de (ID = 359492) Radio
Anglo Española de: Anglo-Nordic 290-FM [Radio] ID = 359492 720x540
Select picture or schematic to display from thumbnails on the right and click for download.
For model Anglo-Nordic 290-FM bafle rejilla madera, Anglo Española de Electricidad S.A. (AEESA)

Country:  Spain
Manufacturer / Brand:  Anglo Española de Electricidad S.A. (AEESA)
alternative name

Sdad. Anglo Esp. de El. || Sociedad Anglo
Brand
AEESA
Year: 1964 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCC85 UCH81 UF89 UABC80 UL84
Semiconductors (the count is only for transistors) Selenium-Rectifier
Main principle Superheterodyne (common)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 125; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 inch = 14 cm
Power out
from Radiomuseum.org Model: Anglo-Nordic 290-FM [bafle rejilla madera] - Anglo Española de Electricidad
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 465 x 190 x 175 mm / 18.3 x 7.5 x 6.9 inch
Notes Rectificador de Selenio.
Net weight (2.2 lb = 1 kg) 4.5 kg / 9 lb 14.6 oz (9.912 lb)
Price in first year of sale 3'482.10 ESP
Literature/Schematics (1) -- Original-techn. papers.

Model page created by José M. Massagué Ferrer. See "Data change" for further contributors.



All listed radios etc. from Anglo Española de Electricidad S.A. (AEESA)
Here you find 186 models, 126 with images and 73 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
