Explorador del Mundo 44-G

Explorador del Mundo 44-G; Anglo Española de (ID = 769161) Radio Explorador del Mundo 44-G; Anglo Española de (ID = 1370951) Radio
Explorador del Mundo 44-G; Anglo Española de (ID = 1370952) Radio Explorador del Mundo 44-G; Anglo Española de (ID = 1370953) Radio
Explorador del Mundo 44-G; Anglo Española de (ID = 1370954) Radio Explorador del Mundo 44-G; Anglo Española de (ID = 1370955) Radio
Explorador del Mundo 44-G; Anglo Española de (ID = 1370956) Radio Explorador del Mundo 44-G; Anglo Española de (ID = 1370957) Radio
Explorador del Mundo 44-G; Anglo Española de (ID = 1709318) Radio
Use red slider bar for more.
Explorador del Mundo 44-G; Anglo Española de (ID = 769161) Radio
Anglo Española de: Explorador del Mundo 44-G [Radio] ID = 769161 926x587
Select picture or schematic to display from thumbnails on the right and click for download.
For model Explorador del Mundo 44-G, Anglo Española de Electricidad S.A. (AEESA):
Cortesia de Getulio

Country:  Spain
Manufacturer / Brand:  Anglo Española de Electricidad S.A. (AEESA)
alternative name

Sdad. Anglo Esp. de El. || Sociedad Anglo
Brand
AEESA
Year: 1952 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 10: EAF42 ECH42 EAF42 ECH42 EM4 EAF42 ECC40 EL41 EL41 AZ2
Main principle Superhet, double/triple conversion; ZF/IF 3500/472,5 kHz
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 90-150 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Explorador del Mundo 44-G - Anglo Española de Electricidad
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 690 x 410 x 320 mm / 27.2 x 16.1 x 12.6 inch
Notes Misma foto aparece en anuncios de modelos para 1954 como 44-GN. Se desconoce si hay cambios internos. A verificar.
Adverts with models for 1954 call the same picture "44-GN" but unknown if there are internal changes. To be verified
Net weight (2.2 lb = 1 kg) 19 kg / 41 lb 13.6 oz (41.85 lb)
Mentioned in Le grand livre de la TSF (Doctsf Ref. 15456)
Literature/Schematics (1) Anuncios La Vanguardia 29/12/1951 - 15/03/1953

Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
