Leo 17 ALT
Use red slider bar for more.
Anglo Española de: Leo 17 ALT [Radio] ID = 630503 448x274
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
alternative name
|
Sdad. Anglo Esp. de El. || Sociedad Anglo | ||||
|---|---|---|---|---|---|
Brand |
AEESA | ||||
| Year: 1950 ?? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 4: ECH41 EAF42 EL41 AZ41 |
| Main principle | Superheterodyne (common); ZF/IF 422,5 kHz; 1 AF stage(s) |
|---|---|
| Tuned circuits | 6 AM circuit(s) |
| Wave bands | Broadcast and Short Wave (SW). |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 125 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm |
| Power out | 4 W (unknown quality) |
| from Radiomuseum.org | Model: Leo 17 ALT - Anglo Española de Electricidad |
| Material | Wooden case |
| Shape | Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only). |
| Dimensions (WHD) | 350 x 210 x 170 mm / 13.8 x 8.3 x 6.7 inch |
| Net weight (2.2 lb = 1 kg) | 3.8 kg / 8 lb 5.9 oz (8.37 lb) |
| Price in first year of sale | 1'894.00 ESP |
| Source of data | -- Original prospect or advert |
| Literature/Schematics (1) | -- Original-techn. papers. |
Model page created by Marcelino Iniesta Fernandez. See "Data change" for further contributors.
All listed radios etc. from Anglo Española de Electricidad S.A. (AEESA)
Here you find 186 models, 126 with images and 73 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
