709; Ansley Radio; New (ID = 790691) Radio

709; Ansley Radio; New (ID = 790692) Radio

709; Ansley Radio; New (ID = 790693) Radio

709; Ansley Radio; New (ID = 790694) Radio

709; Ansley Radio; New (ID = 790695) Radio

709; Ansley Radio; New (ID = 790696) Radio
Use red slider bar for more.
709; Ansley Radio; New (ID = 790691) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Ansley Radio; New York (NY), Trenton (NJ)
Year: 1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 18: 6C4 6BA6 6BE6 6AC7 6E5 6AC7 6SJ7 6SJ7 6H6 6SK7 6SA7 6SK7 6SQ7 6J5 6J5 6V6 6V6 5Y3
Main principle Superheterodyne (common); ZF/IF 456 kHz
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: 709 - Ansley Radio; New York NY,
Material Metal case
Shape Chassis only or for «building in»
Notes identical with "53",see there
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 21, Copyright 1950
Literature/Schematics (1) Riders 21-1 ; 17-2, 3 , 4, 5, 6


All listed radios etc. from Ansley Radio; New York (NY), Trenton (NJ)
Here you find 113 models, 22 with images and 107 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
