• Year
  • 1947
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 128867

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 18
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz
  • Tuned circuits
  • 7 AM circuit(s)     15 FM circuit(s)
  • Wave bands
  • Broadcast, Short Wave plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110 - 120 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Winslow - Ansley Radio; New York NY,
  • Notes
  • This is one of the cabinet styles for the chassis Ansley model 53 (See SAMS Photofact 9-47, set 24, folder 4714-8) which are "Century", "Pembroke", "Conventry", "Normandy", "Whitby", "Winslow", "Plaza", "Salem" and "Skyline". The model 53 is an AC operated Phono-Radio Combination FM-AM Superheterodyne Receiver with Self Contained Loop Antenna and Pushbutton Tuning. The Ansley model 53 is also the radio chassis for the Piano/Phono/Radio-combination "Dynatone 105". For technical data please go to model 53 where we show at least 15 sheets (5 Ryder, 10 SAMS) which you can print out if you are a member.
  • Author
  • Model page created by Ernst Erb. See "Data change" for further contributors.
