• Country
• Denmark

• Manufacturer / Brand
• Rank-Arena, Horsens

• Year
• 1972

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 136089

• • Brand: Arena

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 100 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: R 5000 - Rank-Arena, Horsens

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 470 x 140 x 370 mm / 18.5 x 5.5 x 14.6 inch

• Notes
• UKW: 87,5 - 108 MHz
  MW: 535 - 1605 kHz

  Besonderheiten: MPX-Filter, abschaltbare Loudness, Silent Tuning, MOS-FET im FM-Tuner, integrierte Schaltung, elektron. Sicherung d. Endstufen, Hi- u. Low-Filter, eingeb. Ferritantenne, keramische Filter, Umschaltmöglichkeit für 2 Lautsprechergruppen.

• Net weight (2.2 lb = 1 kg)
• 12 kg / 26 lb 6.9 oz (26.432 lb)

• Price in first year of sale
• 1,075.00 DM

• Source of data
• -- Original prospect or advert

• Mentioned in
• High-Fidelity Jahrbuch 1972

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
