SA9101T
Aristona; Eindhoven
- Country
- Netherlands
- Manufacturer / Brand
- Aristona; Eindhoven
- Year
- 1964 ??
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 304060
-
- Brand: Aristona
Bild aus Aristona Programm 1966
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 7
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Dry Batteries / 6 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 0.5 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: SA9101T - Aristona; Eindhoven
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 280 x 200 x 95 mm / 11 x 7.9 x 3.7 inch
- Notes
-
This recorder is derived from Philips EL3586, see there for additional information.
- Net weight (2.2 lb = 1 kg)
- 3.650 kg / 8 lb 0.6 oz (8.04 lb)
- Mentioned in
- - - Manufacturers Literature ("Aristona - collectie 1966 - technische gegevens")
- Author
- Model page created by Gidi Verheijen. See "Data change" for further contributors.
