Sconosciuto 3 (fonovaligia)

Sconosciuto 3 ; Armstrong; where? (ID = 2299623) R-Player Sconosciuto 3 ; Armstrong; where? (ID = 2299624) R-Player
Sconosciuto 3 ; Armstrong; where? (ID = 2299625) R-Player Sconosciuto 3 ; Armstrong; where? (ID = 2299626) R-Player
Sconosciuto 3 ; Armstrong; where? (ID = 2299627) R-Player Sconosciuto 3 ; Armstrong; where? (ID = 2299628) R-Player
Use red slider bar for more.
Sconosciuto 3 ; Armstrong; where? (ID = 2299623) R-Player
Armstrong; where?: Sconosciuto 3 [R-Player] ID = 2299623 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sconosciuto 3 (fonovaligia), Armstrong; (where?)

Country:  Italy
Manufacturer / Brand:  Armstrong; (where?)
Year: 1965 ?? Category: Sound/Video Recorder and/or Player
Valves / Tubes 2: 35A3 35D5
Main principle Audio-Amplification
Wave bands - without
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Sconosciuto 3 - Armstrong; where?
Material Wooden case
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 330 x 165 x 255 mm / 13 x 6.5 x 10 inch
Notes

controllo volume/tono - giradischi 4 velocità: 16/33/45/78 giri - spia accensione - maniglia di trasporto - cassa con altoparlante nel coperchio - pick-up lesa girevole 33/45-78.

Net weight (2.2 lb = 1 kg) 3.8 kg / 8 lb 5.9 oz (8.37 lb)

Model page created by Edoardo Sigismondo. See "Data change" for further contributors.



All listed radios etc. from Armstrong; (where?)
Here you find 14 models, 14 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
