• Country
• United States of America (USA)

• Manufacturer / Brand
• Arvin, brand of Noblitt-Sparks Industries

• Year
• 1953 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 131170

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 22

• Valves / Tubes
• 6BZ7 or 6BQ7 6J6 6CB6 6CB6 6CB6 6BA6 12AU7 6AC7 6AU6 6AL5 6AV6 6V6GT 12AU7 6SN7GT 6S4 6AL5 6SN7GT 6BQ6GT 6W4GT 1B3GT 5U4G 21MP4

• Main principle
• Superhet with RF-stage

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: 6215CB Del Mar Ch= TE-319 - Arvin, brand of Noblitt-Sparks

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 24.75 x 37 x 21.19 inch / 629 x 940 x 538 mm

• Notes

• Arvin model 6215CB is a 21” b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis TE-319, VHF tuner E25702-1 and picture tube 21MP4, wheat-blond limed oak finish.

• Source of data
• -- Original prospect or advert

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 195, folder 4, dated 2-53)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
