Maestro 104M

Maestro 104M; Asa, Turku (ID = 255785) Radio

Maestro 104M; Asa, Turku (ID = 255786) Radio

Maestro 104M; Asa, Turku (ID = 255787) Radio

Maestro 104M; Asa, Turku (ID = 255788) Radio

Maestro 104M; Asa, Turku (ID = 255789) Radio

Maestro 104M; Asa, Turku (ID = 255898) Radio

Maestro 104M; Asa, Turku (ID = 255899) Radio

Maestro 104M; Asa, Turku (ID = 255901) Radio

Maestro 104M; Asa, Turku (ID = 255903) Radio
Maestro 104M; Asa, Turku (ID = 2457223) Radio Maestro 104M; Asa, Turku (ID = 235907) Radio
Maestro 104M; Asa, Turku (ID = 235908) Radio Maestro 104M; Asa, Turku (ID = 235909) Radio
Maestro 104M; Asa, Turku (ID = 235917) Radio Maestro 104M; Asa, Turku (ID = 235924) Radio
Maestro 104M; Asa, Turku (ID = 255790) Radio Maestro 104M; Asa, Turku (ID = 255791) Radio
Maestro 104M; Asa, Turku (ID = 255792) Radio Maestro 104M; Asa, Turku (ID = 255793) Radio
Use red slider bar for more.
Maestro 104M; Asa, Turku (ID = 2457223) Radio
Asa, Turku: Maestro 104M [Radio] ID = 2457223 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Maestro 104M, Asa, Turku

Country:  Finland
Manufacturer / Brand:  Asa, Turku
Year: 1952 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: DK92 DF91 DAF91 DL94
Main principle Superheterodyne (common); ZF/IF 485 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Line / Batteries (any type) / 127; 220 / 80 & 7,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: Maestro 104M - Asa, Turku
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 315 x 270 x 140 mm / 12.4 x 10.6 x 5.5 inch
Notes A wire loop amtenna buried inside wooden walls of unit.
Net weight (2.2 lb = 1 kg) 3.8 kg / 8 lb 5.9 oz (8.37 lb)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Lasse Nirhamo. See "Data change" for further contributors.



All listed radios etc. from Asa, Turku
Here you find 296 models, 209 with images and 126 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
