Sesam 578

Sesam 578; Asa, Turku (ID = 1327976) Radio Sesam 578; Asa, Turku (ID = 1361382) Radio
Sesam 578; Asa, Turku (ID = 1361383) Radio Sesam 578; Asa, Turku (ID = 1361384) Radio
Sesam 578; Asa, Turku (ID = 1361385) Radio Sesam 578; Asa, Turku (ID = 1361386) Radio
Sesam 578; Asa, Turku (ID = 1361387) Radio
Use red slider bar for more.
Sesam 578; Asa, Turku (ID = 1327976) Radio
Asa, Turku: Sesam 578 [Radio] ID = 1327976 922x692
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sesam 578, Asa, Turku

Country:  Finland
Manufacturer / Brand:  Asa, Turku
Year: 1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH41 UAF41 UAF41 UL41 UY41
Main principle Superheterodyne (common); ZF/IF 485 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 225; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 16 cm = 6.3 inch
Power out
from Radiomuseum.org Model: Sesam 578 - Asa, Turku
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 500 x 340 x 250 mm / 19.7 x 13.4 x 9.8 inch
Notes

Dial lamps: 2x 6,3V / 0,3A

Model page created by Timo Rantasaari. See "Data change" for further contributors.
