• Country
• Argentina

• Manufacturer / Brand
• Astor; Argentina

• Year
• 1950 ??

• Category
• Kit (Parts plus instruction) or building instructions only

• Radiomuseum.org ID
• 158606

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12BE6 12BA6 12AT6 50B5 35W4

• Main principle
• Superheterodyne (common); ZF/IF 465 kHz; 2 AF stage(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• AC/DC-set / 220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• from Radiomuseum.org
• Model: 3S [Miniature tubes] - Astor; Argentina

• Notes
• Tandem triple de 410pF

• Author
• Model page created by Javier Albinarrate. See "Data change" for further contributors.
