GN with 6AN7

GN; Astor brand, Radio (ID = 715043) Radio

GN; Astor brand, Radio (ID = 715044) Radio

GN; Astor brand, Radio (ID = 715045) Radio
GN; Astor brand, Radio (ID = 715046) Radio GN; Astor brand, Radio (ID = 715047) Radio
GN; Astor brand, Radio (ID = 715048) Radio
Use red slider bar for more.
GN; Astor brand, Radio (ID = 715046) Radio
Astor brand, Radio: GN [Radio] ID = 715046 933x608
Select picture or schematic to display from thumbnails on the right and click for download.
For model GN with 6AN7, Astor (brand), Radio Corporation Pty., Ltd.; Melbourne:
Astor model GN

Country:  Australia
Manufacturer / Brand:  Astor (brand), Radio Corporation Pty., Ltd.; Melbourne
alternative name

Radio Corp.of Australia
Year: 1950 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6AN7 6U7G 6B6G 6V6GT 5Y3GT
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
Power out
from Radiomuseum.org Model: GN [with 6AN7] - Astor brand, Radio Corporation
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 490 x 282 x 190 mm / 19.3 x 11.1 x 7.5 inch
Notes This model had three band spread short wave ranges covering the 31, 25 and 19m bands.
Price in first year of sale 37.30 AUS £
Circuit diagram reference Australian Official Radio Service Manual Vol. IX
Literature/Schematics (1) - - Manufacturers Literature (Astor Technical Bulletins, GN-1 to GN-7, 1/5/1950 to 11/9/51.)
Literature/Schematics (2) Australian Official Radio Service Manual AORSM (Volume 9, 1951, Page 39.)
