GN with 6AV6

GN; Astor brand, Radio (ID = 2105400) Radio

GN; Astor brand, Radio (ID = 2105401) Radio
GN; Astor brand, Radio (ID = 2105393) Radio GN; Astor brand, Radio (ID = 2105388) Radio
GN; Astor brand, Radio (ID = 2105389) Radio GN; Astor brand, Radio (ID = 2105395) Radio
GN; Astor brand, Radio (ID = 2105390) Radio GN; Astor brand, Radio (ID = 2105391) Radio
GN; Astor brand, Radio (ID = 2105392) Radio
Use red slider bar for more.
GN; Astor brand, Radio (ID = 2105393) Radio
Astor brand, Radio: GN [Radio] ID = 2105393 1400x1113
Select picture or schematic to display from thumbnails on the right and click for download.
For model GN with 6AV6, Astor (brand), Radio Corporation Pty., Ltd.; Melbourne

Country:  Australia
Manufacturer / Brand:  Astor (brand), Radio Corporation Pty., Ltd.; Melbourne
alternative name

Radio Corp.of Australia
Year: 1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6J8GA 6U7G 6AV6 6V6GT 5Y3GT
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
Power out
from Radiomuseum.org Model: GN [with 6AV6] - Astor brand, Radio Corporation
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 490 x 282 x 190 mm / 19.3 x 11.1 x 7.5 inch
Notes

This model is a variant of Model GN, Serial No, 8457 (with 6J8GA) and (6AN7) tubes.

Radio Corporation Technical Bulletin GN-5 states Type 6AV6 tube.

The type 6B6G  tube will be changed to a type 6AV6 tube in the next production run of the Model GN receiver. The reason for the change is due to a shortage of type 6B6G tubes.

(see attached Technical Bulletin GN-5 and attached Circuit diagram)

Price in first year of sale 37.30 AUS £
Literature/Schematics (1) - - Manufacturers Literature (Astor Technical Bulletins, GN-1 to GN-7, 1/5/1950 to 11/9/51.)

Model page created by Bruce Wilkie. See "Data change" for further contributors.
