A762; Atlantic; Paris (ID = 2066655) Radio

A762; Atlantic; Paris (ID = 2066656) Radio

A762; Atlantic; Paris (ID = 2066657) Radio

A762; Atlantic; Paris (ID = 2066658) Radio

A762; Atlantic; Paris (ID = 2066659) Radio

A762; Atlantic; Paris (ID = 2066660) Radio

A762; Atlantic; Paris (ID = 2066661) Radio

A762; Atlantic; Paris (ID = 2066663) Radio
Use red slider bar for more.
A762; Atlantic; Paris (ID = 2066655) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  France
Manufacturer / Brand:  Atlantic; Paris
Year: 1967/1968 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF124 AF125 AF126 AF126 or. AF116 AF126 or. AF116 AC127 AC128 AC188 AC187 BA102 OA79 or. BA102 OA79 OA79 OA79 BA114
Main principle Super-Heterodyne (Super in general); ZF/IF 455/10700 kHz; 3 AF stage(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: A762 - Atlantic; Paris
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 280 x 170 x 78 mm / 11 x 6.7 x 3.1 inch
Notes

3 gammes d'ondes: PO 520 à 1635 kHz, GO 147 à 265 kHz, FM 87,3 à 108 MHz. HP elliptique 105 x 155 mm. Clavier à 5 touches. HP elliptique 105 x 155 mm. Cadre ferrocapteur fixe, antenne télescopique. Commutateur antenne-cadre.

Coffret gainé souple, cadran noir. Grille bois avec surmoulage plastique noir, boutons noirs avec enjoliveurs. Poignée métallique.

Dans les caractéristique générales, le document technique énumère différents semi-conducteurs que dans le schéma (T4+5 AF126 ou A116, D2 OA79 ou BA102).

Mentioned in -- Original-techn. papers.

Model page created by Mark Hippenstiel. See "Data change" for further contributors.
