Solid State Stereo Amplifier HF-520

Solid State Stereo Amplifier HF-520; Audiola brand - see (ID = 2327709) Ampl/Mixer Solid State Stereo Amplifier HF-520; Audiola brand - see (ID = 2327707) Ampl/Mixer
Solid State Stereo Amplifier HF-520; Audiola brand - see (ID = 2327708) Ampl/Mixer Solid State Stereo Amplifier HF-520; Audiola brand - see (ID = 2327710) Ampl/Mixer
Solid State Stereo Amplifier HF-520; Audiola brand - see (ID = 2327711) Ampl/Mixer Solid State Stereo Amplifier HF-520; Audiola brand - see (ID = 2327712) Ampl/Mixer
Solid State Stereo Amplifier HF-520; Audiola brand - see (ID = 2327713) Ampl/Mixer
Use red slider bar for more.
Solid State Stereo Amplifier HF-520; Audiola brand - see (ID = 2327709) Ampl/Mixer
Audiola brand - see: Solid State Stereo Amplifier HF-520 [Ampl/Mixer] ID = 2327709 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Solid State Stereo Amplifier HF-520, Audiola (brand) - see also New Majestic S.p.a.; Crema, CR

Country:  Italy
Manufacturer / Brand:  Audiola (brand) - see also New Majestic S.p.a.; Crema, CR
Year: 1970 ?? Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Hi-Fi equipment
Power type and voltage Alternating Current supply (AC) / 120; 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 60 W (unknown quality)
from Radiomuseum.org Model: Solid State Stereo Amplifier HF-520 - Audiola brand - see also New
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 300 x 100 x 260 mm / 11.8 x 3.9 x 10.2 inch
Notes

contollo volume/bass/treble/balance - selector Aux/Mag/Tape - mic mixing - commutatori tape/loudness/filter high-low/speaker 1/2 - presa per cuffia - tape P/B rec - potenza uscita: 30+30 watt max - impedenza altoparlanti 8 Ω.

Net weight (2.2 lb = 1 kg) 6.5 kg / 14 lb 5.1 oz (14.317 lb)

Model page created by Edoardo Sigismondo. See "Data change" for further contributors.



All listed radios etc. from Audiola (brand) - see also New Majestic S.p.a.; Crema, CR
Here you find 15 models, 15 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
