Hotpoint Bandmaster B16SG

Hotpoint Bandmaster B16SG; Australian General (ID = 2070136) Radio

Hotpoint Bandmaster B16SG; Australian General (ID = 2070138) Radio
Use red slider bar for more.
Hotpoint Bandmaster B16SG; Australian General (ID = 2070136) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Australia
Manufacturer / Brand:  Australian General Electric (GE Company Australia Ltd., Associated, AGE, Bandmaster, Hotpoint), Sydney
alternative name

General Electric Company of Australia Ltd.
Year: 1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6U7G 6J8G 6U7G 6B8G 6U5 6V6G 5Y3G
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details Record Player (perh.Changer)
Power type and voltage Alternating Current supply (AC) / 200-230; 230-260 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
Power out 4.2 W (undistorted)
from Radiomuseum.org Model: Hotpoint Bandmaster B16SG - Australian General Electric GE
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes

This model has six band-spread short wave ranges. It is similar to the AWA Radiola 316.

Mentioned in Mingay's "Radio Diagram & I.F. Index
Literature/Schematics (1) Australian Official Radio Service Manual, volume 4, page 184.

Model page created by Stuart Irwin. See "Data change" for further contributors.
