- Country
- Australia
- Manufacturer / Brand
- Australian General Electric (GE Company Australia Ltd., Associated, AGE, Bandmaster, Hotpoint), Sydney
- Year
- 1949/1950
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 295404
-
- alternative name: General Electric Company of Australia Ltd.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 4 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Hotpoint J3 J35DM [J35DV4] - Australian General Electric GE
- Shape
- Console with any shape - in general
- Notes
-
Based on the 4 volt vibrator version of AWA Radiola 723C.
Uses a type 19190 synchronous vibrator unit.
See also dry battery, 4 volt accumulator & 6 volt vibrator versions, models J35DA, J35DB & J35DV6
- Price in first year of sale
- 57.70 AUS £
- Literature/Schematics (1)
- Australian Official Radio Service Manual AORSM (Volume 10, 1952, Page 155.)
- Author
- Model page created by Martin Kent. See "Data change" for further contributors.
