Hotpoint-Bandmaster 258DD

Hotpoint-Bandmaster 258DD; Australian General (ID = 755346) Radio

Hotpoint-Bandmaster 258DD; Australian General (ID = 755347) Radio
Use red slider bar for more.
Hotpoint-Bandmaster 258DD; Australian General (ID = 755346) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Australia
Manufacturer / Brand:  Australian General Electric (GE Company Australia Ltd., Associated, AGE, Bandmaster, Hotpoint), Sydney
alternative name

General Electric Company of Australia Ltd.
Year: 1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6U7G 6A8G 6U7G 6G8G 6U5 43 302
Main principle Superhet with RF-stage; ZF/IF 460 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Direct Current supply (DC) / 200-260 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Hotpoint-Bandmaster 258DD - Australian General Electric GE
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes This model uses the same chassis as the AWA Radiola model 268.
Circuit diagram reference Australian Official Radio Service Manual Vol. I I
Literature/Schematics (1) Mingay's Radio Diagram & I.F. Index

Model page created by Stuart Irwin. See "Data change" for further contributors.
