Hotpoint J64MEZ

Hotpoint J64MEZ; Australian General (ID = 988977) Radio

Hotpoint J64MEZ; Australian General (ID = 988978) Radio
Hotpoint J64MEZ; Australian General (ID = 991953) Radio Hotpoint J64MEZ; Australian General (ID = 991960) Radio
Hotpoint J64MEZ; Australian General (ID = 991964) Radio
Use red slider bar for more.
Hotpoint J64MEZ; Australian General (ID = 991953) Radio
Australian General: Hotpoint J64MEZ [Radio] ID = 991953 889x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Hotpoint J64MEZ, Australian General Electric (GE Company Australia Ltd., Associated, AGE, Bandmaster, Hotpoint), Sydney:
Hotpoint J64MEZ. Photo taken with permission from owner.

Country:  Australia
Manufacturer / Brand:  Australian General Electric (GE Company Australia Ltd., Associated, AGE, Bandmaster, Hotpoint), Sydney
alternative name

General Electric Company of Australia Ltd.
Year: 1950 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 6A8G 6AR7GT KT61 5Y3GT
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 1 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 200-230; 230-260 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: Hotpoint J64MEZ - Australian General Electric GE
Material Moulded (Bakelite or Plastics)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Notes This model uses the same chassis as the AWA Radiolette model 520MY.
Circuit diagram reference Australian Official Radio Service Manual Vol. IX

Model page created by Stuart Irwin. See "Data change" for further contributors.
