Hotpoint J75DAZ

Hotpoint J75DAZ; Australian General (ID = 2354668) Radio

Hotpoint J75DAZ; Australian General (ID = 2354669) Radio
Hotpoint J75DAZ; Australian General (ID = 2354663) Radio Hotpoint J75DAZ; Australian General (ID = 2354670) Radio
Hotpoint J75DAZ; Australian General (ID = 2354666) Radio Hotpoint J75DAZ; Australian General (ID = 2354667) Radio
Hotpoint J75DAZ; Australian General (ID = 2354665) Radio
Use red slider bar for more.
Hotpoint J75DAZ; Australian General (ID = 2354663) Radio
Australian General: Hotpoint J75DAZ [Radio] ID = 2354663 1400x1052
Select picture or schematic to display from thumbnails on the right and click for download.
For model Hotpoint J75DAZ, Australian General Electric (GE Company Australia Ltd., Associated, AGE, Bandmaster, Hotpoint), Sydney:
eBay advertisement by seller “re808”, Item Number 382656756534. Please contact Radio Museum to provide more complete photo credit information or request removal.

Country:  Australia
Manufacturer / Brand:  Australian General Electric (GE Company Australia Ltd., Associated, AGE, Bandmaster, Hotpoint), Sydney
alternative name

General Electric Company of Australia Ltd.
Year: 1950 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 1T4 1R5 1T4 1S5 3V4
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Dry Batteries / 2 x 45 & 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
Power out
from Radiomuseum.org Model: Hotpoint J75DAZ - Australian General Electric GE
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Notes

This model uses the same chassis as the AWA Radiola model 453PZ.

Price in first year of sale 45.15 AUS £
Circuit diagram reference Australian Official Radio Service Manual Vol. IX
Literature/Schematics (1) Australian Official Radio Service Manual AORSM (Volume 9, 1951, Page 189.)

Model page created by Stuart Irwin. See "Data change" for further contributors.
