• Country
• New Zealand-Aotearoa

• Manufacturer / Brand
• Autocrat Radio Ltd.; Auckland

• Year
• 1966

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 351292

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 0

• Valves / Tubes
• or

• Number of Transistors
• 14

• Semiconductors
• OC170 2SA60 2SA53 2SA53 2SB54 2SB439 2SB439 2SB54 2SB54 2SB56 2SB56 2SB80 2SB80 2SB80 2SB80

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast and Short Wave (SW).

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 50Hz, 230 Volt

• Loudspeaker
• 2 Loudspeakers

• Power out
• 12 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Solid State Stereogram Gina - Autocrat Radio Ltd.; Auckland

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• 14-transistor dual wave superhet lowboy console stereogram.

  • 4-speed Monarch record changer.
  • 4 - 6 speakers.
  • 6W per channel output.

  See also Autocrat Lynx with the PCB.

• Mentioned in
• -- Original prospect or advert (Press 30 September 1966 Page 9)

• Author
• Model page created by Brian Stevens. See "Data change" for further contributors.
